UNITY ULTRA FLAT DUO
RRP: €59
(Excl. tax)
SKU: 800551
/
Strands Lighting Division
Chosen
Choose
UNITY ULTRA FLAT DUO
SKU: 800551
RRP:
€59
(Excl. tax)
Choose variant
UNITY ULTRA FLAT WORK LIGHT 22W
RRP: €59
(Excl. tax)
SKU: 800552
The unique design and function of the Unity Ultra Flat Duo make it a must-have for any vehicle. This E-approved reversing and warning light (ECE R23/R65) is a powerful tool to increase safety and visibility. It’s incredibly small and flat (90x40x21,8 mm, incl. bracket), yet the wide and precise beam has a range of 24 m, many times stronger than an original light. Better still, the low power consumption of 9 W lets you install as many as needed. The Ultra Flat Duo has a durable construction to survive the exposed positions of a reversing light. With a solid aluminum housing, durable PC lens, and IP rating of IP68/IP69K, you can be sure the Ultra Flat Duo will be a long-lived addition to your vehicle. It has a special coating to further protect it from salt, dirt, and water. Like all Strands products, it’s covered by a 3-year warranty to guarantee its lasting quality.
- Unit PCS
- Voltage (V DC) 10-32V DC
- Consumption (W) 17,5
- Consumption specific function (W) Reverse light:8,5W warning light:9W
- Patterns 1
- Functions Reverse light, warning light
- Theoretical lumen 1100
- Actual lumen 600
- 1 LUX @ m 24
- Color temperature (kelvin) 6000K
- Beam pattern wide beam
- Beam angle (°) (Width) 137,8°
- Connection Cable
- Cable length (mm) 500
- Color housing Black
- Color lens Clear
- Color LED´s White and Amber
- Material housing/chassi Aluminium
- Material lens Polycarbonate
- Length (mm) 90
- Depth (mm) 40
- Height (mm) 15
- Height including bracket (mm) 21,8
- IP-class 68/69K
- Operating temperature -30°C - +65°C
- ADR-approved No
- E-approved Yes
- According to regulation ECE R23, ECE R65
- EMC ECE R10
- Black cable - (Negative)
- Red cable + (Positive) Reverse light
- Yellow cable + (Warning light)
- Mounting details included Side brackets, back bracket, screws, washers, bolts, rubber pad
- Length inner box (mm) 100
- Depth inner box (mm) 63
- Height inner box (mm) 55
- Weight (kg) 0,14
- Length master carton (mm) 295
- Width master carton (mm) 340
- Weight master carton (kg) 8
- PCS in master carton 50
- Warranty 3 Years
TWO FUNCTIONS
WARNING AND REVERSING LIGHT
This incredible reversing light will fit anywhere you need it. With the added functionality of a warning light, you can increase safety for yourself and those around you. It’s indispensable for any working vehicle, where practicality, visibility, power consumption, and safety are of the essence. The Ultra Flat Duo is, of course, E-approved as both reversing and warning light according to ECE R23 and R65.
SUPER SLIM DESIGN
The unique design and function of the Unity Ultra Flat Duo make it an exciting addition to any vehicle. It’s slim, flat, and powerful and can be installed on any vehicle. A standard reversing light will only illuminate a small area, but thanks to the 24 m range of the Ultra Flat Duo, you’ll finally see where you’re going, even in challenging situations. The slim design of the lamp (90x40x21,8 mm, including the bracket) is small enough to fit in your back pocket, enabling installation in hard-to-reach places.
MUST-HAVE FOR ALL PROFESSIONALS
The Unity Ultra Flat Duo combines superb design and powerful technology. It produces an incredibly wide and precise beam with a color temperature of 6000 kelvins and a range of 24 m. The power consumption is only 9 watts, enabling you to install as many as you like. Its size and durability make it a perfect reversing light for illuminating a larger area behind the vehicle. Side and back brackets are included so you can find the ideal placement for your new light.
DURABLE AND 3-YEAR WARRANTY
A reversing light must be extremely durable to survive the exposed positions where it’s installed. Dirt, salt, water, and mud all cause considerable strain to your product. The Ultra Flat Duo is designed with this in mind. It’s constructed from solid aluminum and durable polycarbonate, and the housing has a special coating for extra protection against the elements. The IP rating IP68/IP69K ensures high resistance against water and dirt, and the Ultra Flat Duo is covered by Strands 3-year function warranty to guarantee its longevity.
