UNITY WORK LIGHT 10W LED
Choose variant
UNITY WORK LIGHT/ REVERSING LIGHT 10W LED
Strands UNITY work light 149W LED,10-30V DC, IP67/69K, DT-connector
UNITY WORK LIGHT 64W LED
UNITY WORK LIGHT 19W LED
Strands UNITY work light 31W LED,9-32V DC, IP67/69K, DT-connector
Strands UNITY work light LED 92W,10-32V DC, IP69K, ECE R10
Become a professional with the Unity series. Comes with a perfectly smooth look and a revolutionary strong light output. Extreme power made for demanding tasks.
The Unity series contains seven models, from 10 W to 149 W, and deliver, depending on the size, from 931 to 13,000 actual lumens. The extensive engineering gives you an optimized light spread where you need it the most.
Unity comes in an infinity design. The lens stretches into the corners, providing a great look, resisting dirt, and allowing the light output to reach its full potential. The slim design perfectly matches today´s modern vehicles needing work lights like trucks, tractors, trailers, construction, or agricultural machinery.
When it comes to powerful lighting, they usually produce more heat, which means the lamp can break. The built-in temperature control prevents that, and the function protects the lamp and decreases the power until the light is cooled down. This function makes the Unity series one of the most durable products on the market.
- Voltage (V DC) 10-32V DC
- Theoretical lumen 1520
- Actual lumen 931
- 1 LUX @ m 44
- Color temperature (kelvin) 6500K
- Beam pattern Flood
- Position light No
- Connection DT
- Cable length (mm) 500
- Color housing Black
- Color lens Clear
- Color LED´s White
- Material bracket Stainless steel
- Material housing/chassi Aluminium
- Material lens Polycarbonate
- Length (mm) 52,11
- Depth (mm) 26,13
- Height (mm) 67,03
- Height including bracket (mm) 75,06
- IP-class 68
- Operating temperature -30°C - +65°C
- EMC ECE R10
- Black cable - (Negative)
- Red cable + Positive
- Mounting details included Screws, washers, bolts
- Length inner box (mm) 100
- Depth inner box (mm) 63
- Height inner box (mm) 55
- Weight (kg) 0,2
- Length master carton (mm) 295
- Width master carton (mm) 340
- Weight master carton (kg) 11
- PCS in master carton 50
SEVEN MODELS
The Unity series contains seven models, from 10 W to 149 W. Developed to enhance your capabilities and precisely control heavy machinery during the darkest hours of the day.
INFINITY DESIGN
The infinity design, where the lens stretches into the corners, provides a great look and resists dirt, allowing the light output to reach its full potential. The slim design makes Unity a perfect match together with today´s modern vehicles like trucks, tractors, trailers, and construction- or agricultural machinery.
HIGH POWER
Unity has a revolutionary strong light output and gives you an optimized light spread where you need it the most. Delivers 931 to enormous 13,000 actual lumens depending on the size.
BUILT-IN TEMPERATURE CONTROL
When it comes to powerful lighting, they usually produce more heat, which means the lamp can break. The built-in temperature control prevents that, and the function protects the lamp and decreases the power until the light is cooled down. This function makes the Unity series one of the most durable products on the market.
