SIBERIA XPA DR LED BAR 12″
/
Strands Lighting Division

SIBERIA XPA DR LED BAR 12″

White/Amber Pos. | Extended Beam | DT-4Pin
SKU: 809426A
RRP: €245 (Excl. tax)

Choose variant

SIBERIA XPA DR LED BAR 12″

RRP: €245 (Excl. tax)
SKU: 809426A
Chosen

SIBERIA XPA DR LED BAR 8″

RRP: €179 (Excl. tax)
SKU: 809425A
Choose

SIBERIA XPA DR LED BAR 42″

RRP: €564.10 (Excl. tax)
SKU: 809429A
Choose

SIBERIA XPA DR LED BAR 32″

RRP: €492.20 (Excl. tax)
SKU: 809428A
Choose

SIBERIA XPA DR LED BAR 22″

RRP: €307.20 (Excl. tax)
SKU: 809427A
Choose

SIBERIA XPA DR LED BAR 50″

RRP: €666.80 (Excl. tax)
SKU: 809430A
Choose
Buy in store Buy in USA
Manual Product sheet

The Siberia XPA Double Row 12“ LED bar produces over 6100 actual lumens and a more than 520-meter range in Xperience mode. It’s a true lighting experience with an extended beam pattern. This means a 100% increase in output compared to previous models and high forward visibility. If you like the amber glow, the XPA LED bars have a new dual-color position light in amber and white. The Siberia XPA is a long-lasting addition to any vehicle thanks to the durable materials and new powder coating. It’s IP-rated IP68/IP69K, which gives high protection against dirt and water. The installation is easy thanks to the DT-4 connector and 550 mm cable. The E-mode is E-approved R149/148 with reference number 20. The XPA DR LED bars are covered by Strands Lighting Division’s 3-year function warranty.

    • Unit pcs
    • Voltage 10-32V DC
    • Theoretical effect 100W
    • Consumption 84W
    • Functions Driving light,Amber and white position light
    • Consumption specific function Xperience mode: 84W / E-mode: 25W / White position light: 11,6W /Amber position light: 11,5W
    • Theoretical lumen 6757lm
    • Actual lumen E-mode: 1925lm / Xperience mode: 6120lm
    • 1 lux @ E-mode: 300m / Xperience mode: 529m
    • Color temperature 5700K
    • Beam pattern Extended beam
    • Beam angle 15,4°
    • Connection DT-4PIN
    • Cable length 550mm
    • Color housing Black
    • Color lens Clear
    • Color LED´s White/amber
    • Material bracket Aluminium alloy
    • Material housing/chassi Aluminium
    • Material lens Polycarbonate
    • Length 310,4mm
    • Depth 71,6mm
    • Height 76mm
    • Height including bracket 96,6mm
    • Weight 1,45kg
    • IP-class IP68/69K
    • Operating temperature -35 - +60°C
    • E-approved Yes
    • According to regulation ECE R148,R149
    • Reference number 20
    • EMC ECE R10
    • Black cable - (Negative)
    • Red cable + (Positive)
    • White cable White Position light
    • Yellow cable Amber Position light
    • Included in package Rear hanging Bracktes, screws, washers, bolts, rubber pads, DT06 pig tail, No inbulit-relay
    • Length inner box 465mm
    • Width inner box 115mm
    • Height inner box 125mm
    • Gross weight 1,61kg
    • Volume 0,007m³
    • Warranty 3 Years
    • Length master carton 790mm
    • Width master carton 380mm
    • Height master carton 390mm
    • Weight master carton 2,15kg
    • PCS in master carton 9pcs

I AM XPERIENCE

AMBER POSITION LIGHT

The Siberia XP series is a true trailblazer when it comes to power, durability, and design. As the series grows, every driver can find the perfect option to suit their style. With the XPA, fans of the amber glow can get both the position light of their dreams and unbeatable Siberia XP quality. If a white position light is more in your lane, the XPA has that as well. All XPA LED bars over 20” have the eye-catching Hello function for the position lights. Just flash your high beam twice, and the position lights activate their dynamic Hello to greet your fellow drivers.

EFFORTLESS INSTALLATION

Embrace the journey and live life to the fullest. Let the Siberia XPA guide you down rough roads with maximum brightness and solid construction. The XP driving lights are designed for high durability and high vibration protection to withstand hardships on or off-road. The XPA comes with a DT-connector, saving you time and energy. Everything else needed for installation is included.

A NEW EXTREME OUTPUT

Thanks to the efficient use of LED technology, the Siberia XPA LED bars have an incredibly improved output compared to previous models. Thanks to this, you will always get the perfect illumination under clear skies or in stormy weather, with up to 100% stronger output than previous. All LED bars can be used with Xperience mode and E-mode to provide ideal illumination under all circumstances. The Xperience mode is an authentic adventure with over-the-top output, giving you complete freedom of exploration anywhere. The E-mode is E-approved and a good option when driving in rain, fog, and snow to reduce glare from water particles.

I AM XPERIENCE

Experience joyful driving along rough roads. Nothing is left to chance in the Siberia XPA; every detail has been rigorously tested and improved, from the light output to the lens and housing to the installation. A new powder coating protects the housing against weather and rugged use, and the durable construction is built to withstand high vibration levels. It will be a long-lived product, even when exposed to salted roads, and it has a quality you can feel. Everything guarantees flawless visibility in all conditions and an easy-to-install product that will endure any storm.
