SIBERIA XP HEAT WORK LIGHT
XPERIENCE HEAT: never let ice-covered lights slow you down again. The robust and heavy-duty Siberia XP Heat has a heated lens, keeping it free from ice in cold and wet weather. A massive output of 3710 actual lumens and a 68-meter range offer maximum visibility in any storm. The automatic heating function connects with a separate cable and activates when the temperature reaches or falls below 5°C to keep the lens ice-free. An IP rating of IP68/IP69K, a solid aluminum housing, and a tempered glass lens guarantee lasting quality. Its sturdy, vibration-resistant build is designed for heavy-duty use and is a perfect fit for trucks and other heavy vehicles. It has red and amber position lights that can be connected to the heating function or the indicator lights. Installation is easy thanks to a 2000 mm cable.
- Unit PCS
- Voltage (V DC) 10-32V DC
- Consumption (W) 70
- Consumption specific function (W) Red position light:1,4W Amber position light:1,7W Heating lens:25W
- Functions Work light,Red and amber position light, Heating lens function with separate wire
- Theoretical lumen 6000
- Actual lumen 3710
- 1 LUX @ m 68
- Color temperature (kelvin) 5700
- Beam pattern wide beam
- Beam angle (°) (Width) 90,4°
- Position light Red and amber
- Connection Cable
- Cable length (mm) 2000
- Color housing Black
- Color lens Clear
- Color LED´s White, Red and Amber
- Material bracket Stainless steel
- Material housing/chassi Aluminium
- Material lens Tempered glass
- Length (mm) 110,44 , with frame 140
- Depth (mm) 75,45, with frame 80,09
- Height (mm) 110,34, with frame 134,99
- Height including bracket (mm) 119,17
- CC (mm) L1:125 L2:50 with flush mount frame
- IP-class 68/69K
- Operating temperature -30°C - +65°C
- E-approved No
- EMC ECE R10
- Black cable - (Negative)
- Red cable + Red position light (Positive)
- White cable + Work light
- Yellow cable + Amber Position light(Positive)
- Grey cable + Heating lens (Positive)
- Mounting details included Brackes,Screws, washers, bolts, flush mount frame
- Length inner box (mm) 213
- Depth inner box (mm) 198
- Height inner box (mm) 130
- Weight (kg) 1,4
- Length master carton (mm) 445
- Width master carton (mm) 690
- Weight master carton (kg) 29
- PCS in master carton 20
- Warranty 3 Years
I AM HEAT
HEAVY-DUTY QUALITY
Plowing, towing, forest work, and many other challenging jobs require the best products. Where performance and safety are in the front seat, you can trust XP Heat to do the job. Its powerful output, solid size, and heavy-duty materials make it a perfect fit for trucks and other heavy vehicles. With a robust aluminum housing and tempered glass lens, Siberia XP Heat will endure any challenge. An IP rating of IP68/IP69K and high vibration resistance guarantees lasting performance.
MAXIMUM OUTPUT
You are in control. The XP Heat has a powerful output, letting you focus on the job ahead. With a range of 68 meters and a 3710 actual lumens brightness, the wide beam guarantees high visibility even in the darkest night. A color temperature of 5700 K provides a bright and clear beam. The efficient use of materials and technology results in a low power consumption for such a powerful light, consuming only 30 W.
XPERIENCE HEAT
In the harshest weather, you need products you can trust no matter what. The Siberia XP Heat never lets you down, even during the longest winter nights. Thanks to the heated lens, snow or rain won’t turn into ice when hitting the lens, guaranteeing high visibility year-round. The automatic heating function activates at temperatures below 5° C. It connects with a separate cable and can be connected to the position lights, activating them simultaneously.
POWER AND GLOW
The Siberia XP series is defined by the unique shapes and colors of the position lights. In the XP Heat, you’ll find amber and red position lights that can be connected in different ways. When connected to the heating function, the position lights glow when the heat is activated. Or connect the position light to the vehicles’ indicator lights for extra visibility.
