DARK KNIGHT INSANE LIGHT
/
Strands Lighting Division

DARK KNIGHT INSANE LIGHT

SKU: 270698
RRP: €287.70 (Excl. tax)
Buy in store Buy in USA
Manual Product sheet

Get ready to go Insane. To go from 0 to 100. Dark Knight Insane is here, the newest member of the Dark Knight series. With all your lighting needs into one single lamp: A driving light with duo position light and warning light. Created with passion and loaded with all the features you want. Dark Knight Insane is a confident, futuristic Dark Knight charged with power and brightness in full intensity. Ready for a powerful driving experience beyond the ordinary.

An oval driving light with warning light and position light with duo function, choose between amber and white light.Insane creates your chance to live out your passion and become an unstoppable Dark Knight. With a beam pattern created for the hard-working driver, in need of a perfect balance between length and width. The total efficiency collects and directs the light, exactly where you need it.Insane radiates self-confidence both day and night. Intended to be seen from all angles on the road and as to drive in daylight even during the dark hours of the night. Meet the fearless Knight’s eyes from the unique position light. See and enjoy the soft starting effect, where the light slowly increases in intensity before it finally reaches its full capacity.

With dark details and slim design, it is easy to mount many in a row and quickly become one with your vehicle. Combined with advantage together with the other members of the Dark Knight series to create a harmonious unit.

    • Unit pcs
    • Voltage 10-36V DC
    • Theoretical effect 160W
    • Consumption 98W
    • Functions Driving light, position light, warning light
    • Consumption specific function White position light: 1,5W, Amber position light: 1,5W, Warning Light: 6W
    • Patterns 5
    • Theoretical lumen 12000lm
    • Actual lumen 10500lm
    • 1 lux @ 437m
    • Color temperature 5700K
    • Beam pattern Optimized beam
    • Beam angle 18,6
    • Connection Cable
    • Cable length 2500mm
    • Color housing Black
    • Color lens Clear
    • Color LED´s White/amber
    • Material bracket Stainless steel
    • Material housing/chassi Aluminium
    • Material lens Polycarbonate
    • Length 247mm
    • Depth 70,7mm
    • Height 141mm
    • Height including bracket 170,5mm
    • Weight 1,845kg
    • IP-class IP68/69K
    • Operating temperature -40 - +60°C
    • E-approved Yes
    • According to regulation ECE R7, R65, R112
    • Reference number 45
    • EMC ECE R10
    • Black cable - (Negative)
    • Red cable + (High-beam)
    • Blue cable Pattern selection and warning light syncronization
    • Yellow cable + Amber Position light(Positive)
    • Green cable Warning light
    • Grey cable + White position light(Positive)
    • Included in package Bracket, Screws, washers, bolts
    • Length inner box 294mm
    • Width inner box 243mm
    • Height inner box 107mm
    • Gross weight 2,05kg
    • Volume 0,008m³
    • Warranty 3 Years
    • Length master carton 510mm
    • Width master carton 315mm
    • Height master carton 345mm
    • Weight master carton 12,3kg
    • PCS in master carton 6pcs

GET READY TO GO INSANE

ONE LAMP - THREE FUNCTIONS

Dark Knight Insane makes it possible to get all the lighting you need in a single lamp: a driving light with warning light and duo position light, choose between amber and white. Insane is created with passion and loaded with all the features you need to get a powerful driving experience beyond the ordinary. Your chance to live out your passion and become an unstoppable Dark Knight.

HIGH PERFORMANCE

Dark Knight Insane is intended to be visible from all angles on the road and like driving in daylight even at night. A beam pattern created for the hard-working driver, in need of a perfect balance between length and width. The technology improves the overall efficiency, collects, and directs light in a perfect balance, exactly where you need it. Dark Knight Insane radiates confidence, both day and night. Meet the fearless Knight’s eyes from the unique position light. See and enjoy the soft start effect, where the light slowly increases in intensity before it finally reaches its full capacity.

DARK KNIGHT DESIGN

Insane is a confident, futuristic, black knight charged with power and brightness in full intensity. Dark details and slim design make it easy to mount and quickly becomes one with your vehicle. With Dark Knight Insane you can mount as many as you want in a row. Combined with advantage together with the other members of the Dark Knight series to create a harmonious unit.
