SWEDSTUFF DRIVING LIGHT 7″ 65W
White/Amber Pos. | Optimized Beam | DT-4PinChoose variant


SWEDSTUFF DRIVING LIGHT 9″ 95W
Compact Yet Powerful LED Light with Dual Position Function
The Driving Light NEW 7” is a cutting-edge LED solution designed for optimal performance and visibility. Perfect for enhancing your vehicle’s lighting system, this driving light combines high-beam functionality with stylish amber and white position lights. Engineered for various applications, it ensures you always have a clear view of the road ahead.
Key Features:
• Powerful Illumination: With a theoretical output of 3200 lumens and an actual output of 3100 lumens, this driving light provides exceptional brightness, ensuring optimal visibility even in challenging conditions.
• Optimized Beam Pattern: Designed with a precision-optimized beam, this light offers superior road coverage, ensuring safety and clarity at all times.
• Dual Position Lights: The versatile amber and white position lights enhance both functionality and style, allowing you to customize your vehicle’s appearance.
• Robust Construction: Made from durable aluminum housing and a tough polycarbonate lens, this light is built to last, even in harsh environments.
• IP67 & IP69K Rated: Fully dustproof and waterproof, this driving light can withstand extreme conditions, from heavy rains to dusty trails.
Ideal Applications:
• Off-road driving
• Trucks and heavy vehicles
• Agricultural equipment
• Emergency and utility vehicles
- Unit pcs
- Voltage 10-32V DC
- Theoretical effect 72W
- Consumption 65W
- Functions High beam, Amber and white position light
- Consumption specific function White position light: 1,4W / Amber position light: 1,4W
- Theoretical lumen 3200lm
- Actual lumen 3100lm
- 1 lux @ 496m
- Color temperature 5700K
- Beam pattern Optimized beam
- Connection DT-4PIN
- Cable length 1000mm
- Color housing Black
- Color lens Clear
- Color LED´s White/amber
- Material bracket Stainless steel
- Material housing/chassi Aluminium
- Material lens Polycarbonate
- Length 178,23mm
- Depth 76,14mm
- Height 178,23mm
- Height including bracket 192,77mm
- Diameter 178,23mm
- Weight 1,35kg
- IP-class IP67/69K
- Operating temperature -35 - +60°C
- E-approved Yes
- According to regulation ECE R148, R149
- Reference number 50
- EMC ECE R10
- Black cable - (Negative)
- Red cable + (Positive)
- White cable White Position light
- Yellow cable Amber Position light
- Included in package Brackets ,Screws, Washers, Bolts, Rubber pad, Deutsch plug
- Length inner box 271mm
- Width inner box 143mm
- Height inner box 224mm
- Gross weight 1,5kg
- Volume 0,0087m³
- Warranty 1 Years
- Length master carton 550mm
- Width master carton 310mm
- Height master carton 466mm
- Weight master carton 1,4kg
- PCS in master carton 8pcs
