FREEDOM MAXIMUM POSITION DRIVING LIGHT 9″ DARK POSITION LIGHT

SKU: 270935
RRP: €399 (Excl. tax)

Choose variant

FREEDOM MAXIMUM POSITION DRIVING LIGHT 9″ DARK POSITION LIGHT

RRP: €399 (Excl. tax)
SKU: 270935
Chosen

FREEDOM MAXIMUM POSITION DRIVING LIGHT 7″ DARK POSITION LIGHT

RRP: €389 (Excl. tax)
SKU: 270933
Choose
Buy in store Buy in USA
Manual Product sheet

Enhance your style to the max. The Freedom Maximum Position driving light 9” is full of brightness and personality and has a dark position light. Innovative technology renders the position light invisible when not in use and reveals the distinct shape and white and amber glow when activated. The amber light is E-approved both as a forward position light and a side marker ECE R148(R7, R91), R149 (R112).

With a 3 m cable, it is easy to install in various places on your vehicle. Thus, you can create the optimal driving experience wherever the road takes you. The optimized beam has a range of 406 m @ 1 Lux, ensuring high visibility ahead. An incredible brightness of 13400 lumens and a 5700-kelvin color temperature combine for a powerful illumination.

The Maximum Position 9” is made in Europe to reduce transport and environmental strain. With durable materials backed by Strands Lighting Division’s 3-year warranty, it will be a lasting addition to any vehicle. The solid design suits heavier vehicles, such as jeeps and trucks, or anywhere you need intense brightness and eye-catching style. Freedom MP is IP-rated IP69K for maximum durability to withstand dirt, liquids, and exposure to the elements.

    • Unit PCS
    • Voltage (V DC) 12-24V DC
    • Consumption (W) 113
    • Consumption specific function (W) Front pos.:3,3W Side marker: 10W
    • Functions Driving light, front pos., side marker
    • Theoretical lumen 16700
    • Actual lumen 13400
    • 1 LUX @ m 406
    • Color temperature (kelvin) 5700K
    • Beam pattern Optimized beam
    • Beam angle (°) (Width) 23,2°
    • Position light White and amber
    • Connection Cable
    • Cable length (mm) 3000
    • Color housing Black
    • Color lens Clear
    • Color LED´s White and Amber
    • Material bracket Stainless steel
    • Material housing/chassi Aluminium
    • Material lens Polycarbonate
    • Depth (mm) 6,4
    • Height including bracket (mm) 245
    • Diameter (mm) 228
    • IP-class 69K
    • Operating temperature -40 - +40°C
    • E-approved Yes
    • According to regulation ECE R148(R7,R91), R149(R112)
    • Reference number 37,5
    • EMC ECE R10
    • Black cable + Front pos. light
    • Red cable + Side marker light
    • White cable - Negative
    • Green cable (+)High beam
    • Mounting details included Bracket, Screws, washers, bolts
    • Length inner box (mm) 285
    • Depth inner box (mm) 110
    • Height inner box (mm) 285
    • Weight (kg) 2,6
    • Length master carton (mm) 410
    • Width master carton (mm) 330
    • Weight master carton (kg) 10,98
    • PCS in master carton 4
    • Warranty 3 Years

DARK POSITION LIGHT

FREEDOM, MADE IN EUROPE

The Freedom Maximum Position is proudly made in Europe, minimizing transport and environmental impact. With a solid design and manufacture, the reliable aluminum and polycarbonate materials will ensure your product is long-lived. It is also backed by Strands Lighting Divisions’ 3-year function warranty.

DARK POSITION LIGHT

This new take on position light technology will render it invisible against the black housing when not in use. When the amber glow of the position lights is activated, you’ll be met with an eye-catching shape and design. The amber light is E-approved both as a forward position light and a side marker ECE R148(R7, R91), R149 (R112).

BRIGHTNESS AND PERSONALITY

The 13400 lumens provide an exemplary brightness, and the color temperature of 5700 kelvins ensures powerful and easy-on-the-eye illumination. The optimized beam, which measures 1 Lux @ 406 meters, gives high visibility ahead. It will increase the visual range and draw attention to your vehicle.
